FAAC-D700HS/KIT drive drive
Drive for the Genius-Sirocco-250/Kit wing gate-FAAC double-leaf gate kit

Drive for the Genius-GBAT-300/KIT winger gate-FAAC double-leaf gate kit

0 out of 5
(There is no product opinion yet.)

1694,43 zloty

Gate drive type: mechanical ; Maximum string: 3500 N ; Maximum gate length: 3 m (single wing with the option of electromagnetic lock) ; Linear speed: 16 mm/s (max) ; Rotation angle: 110 ° (max) ; Wireless transmission range: ≥ 50 m (in open field) ; Selected features: self -locking drive ;

AVAILBILITY: 4 In the SKU magazine: Genius-Gbat-300/Kit Categories: , , ,

Description

Gate drive type:Mechanical, to the wing gates - a set for a double gate
Maximum string:3500 N
Engine type:Single -phase, 230 V AC
Maximum gate length:3 m (single wing with the option of electromagnetic lock)
Linear speed:16 mm/s (max)
Rotation angle:110 ° (max)
Automatic closing of the gate:
Automatic drive blocking:
Marginal switch:
It is possible to connect a photocell:
Possibility to connect the signal lamp:
Maximum number of programmed pilots:255 channels
Wireless transmission range:≥ 50 m (in open field)
System operation frequency band :433.92 MHz
Number of cycles per hour:≤ 30
Selected features:
  • Self -brake drive
  • The set includes assembly brackets:
    • rear bracket (to the post) for welding/screwing
    • front bracket (to the wing) for welding
  • Included housing for the controller
    • Power supply:220 ... 240 V AC , 50 /60 Hz
    Case:
  • Plastic + metal (G-Bat 300 cylinder)
  • Plastic (controller housing)
    • Tightness class:
  • IP44 (G-Bat 300 actuator)
  • IP55 (controller housing)
    • Color:
  • Black (G-Bat 300 cylinder)
  • Light gray (driver housing)
    • Work temperature:-20 ° C ... 55 ° C
    Libra:5.6 kg (single gate cylinder)
    Dimensions:
  • 640 x 107 x 185 mm (single gate cylinder)
  • 265 x 205 x 87 mm (controller housing)
    • Manufacturer / brand:FAAC / GENIUS
    Guarantee:2 years

    Download materials:

    Additional information

    Libra 17.2000 kg
    Dimensions 80 × 30 × 25 cm
    Libra

    17.2000
    Length

    80
    Width

    30
    Height

    25
    Ean

    8055195065435
    Producer

    Faac
